Robust drilling outcomes level to development and upgrades in copper-gold useful resource

The principle Nook Bay deposit is demonstrating glorious continuity and grade in addition to exploration upside, as proven by our earlier drilling outcomes of as much as 9.7% CuEq outdoors the useful resource.

Exploration has additionally delivered a brand new goal with glorious outcomes which might be near-surface and inside 4km of the 100 per cent-owned central processing facility.

The newest exploration outcomes stem from the continuing evaluation of historic knowledge, together with drill logs that haven’t been checked out in over 30 years and by no means earlier than in trendy 3D software program.

This makes it a extremely environment friendly and efficient approach to set up new areas of mineralisation on this substantial mining camp. We sit up for uncovering extra areas like Colline as a part of our technique to develop our high-grade copper-gold portfolio”.

• All drilling carried out by Cygnus Metals on the Chibougamau Mission was accomplished underneath the supervision of a registered skilled geologist as a Certified Individual (QP) who’s accountable and accountable for the planning, execution, and supervision of all exploration exercise in addition to the implementation of high quality assurance packages and reporting.
• All Cygnus drilling reported is NQ dimension (47.8 mm diameter).
• All historic drilling carried out at Chibougamau Mission (as is normal follow in Quebec) was accomplished underneath the supervision of a registered skilled geologist as a Certified Individual (QP) who’s accountable and accountable for the planning, execution, and supervision of all exploration exercise in addition to the implementation of high quality assurance packages and reporting.
• Historic drilling on the Chibougamau Mission is historic in nature courting again to the Fifties. All drilling was carried out utilizing diamond drill rig with each BQ and NQ sized core.

• All pattern assortment, core logging, and particular gravity determinations had been accomplished by Cygnus Metals underneath the supervision of a professionally certified registered geologist.
• NQ core was marked for splitting throughout logging and is sawn utilizing a diamond core noticed with a mounted jig to guarantee the core is lower lengthwise into equal halves.
• Half of the lower core is positioned in clear particular person plastic baggage with the suitable pattern tag.
• QA/QC is finished in home by Cygnus Metals geologists with oversight from the Senior Geologist. The test samples (blanks and requirements – 4% of whole samples with one other 2% of core duplicates taken on half cut up core) that had been inserted into the pattern batches are verified towards their licensed values and are deemed a cross if they’re inside 3 normal deviations of the licensed worth. The duplicates are evaluated towards one another to find out mineralization distribution (nugget). If there are giant discrepancies within the test samples, then the complete batch is requested to be re-assayed. The samples are then positioned in baggage for cargo to the offsite laboratory’s facility.
• The remaining half of the core is retained and integrated into Cygnus’s safe, core library positioned on the property.
• As a result of historic nature of the above reported historic outcomes, detailed details about pattern representivity isn’t accessible, subsequently the info might be unreliable.

In circumstances the place ‘trade normal’ work has been accomplished this is able to be comparatively easy (eg ‘reverse circulation drilling was used to acquire 1 m samples from which 3 kg was pulverised to provide a 30 g cost for hearth assay’). In different circumstances extra clarification could also be required, equivalent to the place there may be coarse gold that has inherent sampling issues. Uncommon commodities or mineralisation varieties (eg submarine nodules) might warrant disclosure of detailed info.

• Business normal sampling practices had been used with pattern lengths starting from 0.3 m to 1.0 m and revered geological contacts. Pattern tags had been positioned at first of every pattern interval and the tag numbers had been recorded in an MS Excel database.
• Sampling follow is taken into account to be acceptable to the geology and elegance of mineralisation.
• Historic sampling was usually carried out on smaller interval right down to 0.1m, paper logs exist recording all requisite info. The sampling follow is taken into account to be acceptable to the geology and elegance of mineralisation.

• Diamond core was drilled utilizing floor diamond rigs with trade recognised contractors Miikan Drilling. Miikan is a three way partnership between Chibougamau Diamond Drilling Ltd., the First Nations group of Ouje-Bougoumou and the First Nations group of Mistissini each positioned within the Eeyou Istchee territory.
• Drilling was carried out utilizing NQ core dimension.
• Directional surveys have been taken at 50m intervals.
• All historic drilling carried out on the Chibougamau Mission was carried out utilizing diamond drill rig with each BQ and NQ sized core.

Measures taken to maximise pattern restoration and guarantee consultant nature of the samples.

Whether or not a relationship exists between pattern restoration and grade and whether or not pattern bias might have occurred attributable to preferential loss/achieve of positive/coarse materials.

• Diamond core restoration was measured for every run and calculated as a proportion of the drilled interval.
• Total, the core recoveries are glorious within the Chibougamau space. Because of this, no bias exists.

• All core was geologically and geotechnically logged. Lithology, veining, alteration and mineralisation are recorded in a number of tables of the drillhole database.
• Historic drilling has been recorded on paper logs which have been scanned and digitised into MS Excel by Cygnus and different skilled geologists.

• Geological logging of core is qualitative and descriptive in nature.

• 100% of the core has been logged.

If non-core, whether or not riffled, tube sampled, rotary cut up, and so forth and whether or not sampled moist or dry.

For all pattern varieties, the character, high quality and appropriateness of the pattern preparation method.

High quality management procedures adopted for all sub-sampling phases to maximise representivity of samples.

Measures taken to make sure that the sampling is consultant of the in-situ materials collected, together with as an example outcomes for subject duplicate/second-half sampling.

Whether or not pattern sizes are acceptable to the grain dimension of the fabric being sampled.

• The NQ diameter the core was sawn in half following a pattern slicing line decided by geologists throughout logging and submitted for evaluation on nominal 1m intervals or outlined by geological boundaries decided by the logging geologist.
• Every core pattern is assigned a tag with a singular figuring out quantity. Pattern lengths are sometimes one metre however might be relying on zone mineralogy and bounds.
• This sampling method is trade normal and deemed acceptable.
• For historic drilling: the marked drill gap core sections had been cut up utilizing a hydraulic core splitter. Half core was put in plastic baggage numbered on the surface with a pen marker. A pattern tag was positioned inside the baggage and the baggage had been folded and stapled. The pattern baggage had been then despatched to the Copper Rand mine laboratory for evaluation. The remaining core was retained for reference.
• Samples sizes are thought of acceptable to grain dimension of the supplies being sampled.

• Pattern (NQ dimension half core) preparation and hearth assay evaluation had been accomplished at Bureau Veritas Commodities Canada Ltd (“BV”) in Timmins, Ontario, and ICP-ES multi-elements evaluation was accomplished at BV in Vancouver, B.C.
• Samples had been weighed, dried, crushed to 70% passing 2 mm, cut up to 250 g, and pulverized to 85% passing 75 µm.
• Samples are hearth assayed for gold (Au) (30 g) and multi-acid digestion ICP-ES end, for 23 parts (together with key parts Ag, Cu, Mo).
• Samples assaying >10.0 g/t Au are re-analysed with a gravimetric end utilizing a 30 g cost. Samples assaying >10% Cu are re-analysed with a sodium peroxide fusion with ICP-ES evaluation utilizing a 0.25 g cost.
• Traditionally, samples had been delivered to the in-house laboratory at Copper Rand. Management samples had been despatched to an exterior laboratory.

• At Bureau Veritas, laboratory QC procedures contain the usage of inside licensed reference materials as assay requirements, together with blanks, duplicates and replicates.
• For historic assays accomplished on the on-site laboratory, samples had been transferred into steel pans. Paper baggage had been ready, and the pattern numbers had been recorded on them. The samples had been crushed to -0.25 in (-6.35 mm) and cut up to maintain 100 to 200g. Rejects had been put again into the plastic baggage and saved.
• The cut up was pulverized with a disk pulverizer and the pulp was saved within the paper bag. A 5 g pattern was weighed and put in a beaker. Trays of 35 beakers had been used. The samples had been dissolved utilizing a mix of 20 mL of hydrochloric acid (HCl) and 10 mL of nitric acid. The trays had been then heated for 5 minutes and left to sit down and funky for 45 minutes.
• The answer was vacuum filtered into Erlenmeyer flasks and levelled to 100 ml. The Erlenmeyer flasks had been combined for one minute. The answer was then positioned into check tubes, 35 check tubes per tray, and diluted with water at a ratio of 1:15.
• The check tubes had been subjected to evaluation by atomic absorption for copper, gold, and silver. Outcomes had been displayed on the display screen of the atomic absorption analyzer. There was no digital storage of outcomes. Assay outcomes had been manually transcribed onto assay sheets by the operator. They had been later entered into laptop spreadsheets for additional processing by the geology division. The handwritten assay sheets had been archived in recordsdata on the laboratory.

• Verification of sampling was made by Cygnus Metals and different skilled marketing consultant geologists.
• Verification of historic unique drillhole logs and assay knowledge was made by Cygnus and different skilled geologists.

• All logging knowledge was accomplished, core marked up, logging and sampling knowledge was entered immediately into the database.
• The logged knowledge is saved on the location server immediately.
• For historic log, all knowledge is recorded on pdf studies a lot of that are filed with the Quebec authorities – Ministry of Pure Assets and Forests.

• There was no adjustment to the assay knowledge.

• The situation of the drillholes and the aiming factors for the orientation of the drillholes had been indicated on the bottom utilizing recognized stakes. The stakes marking the situation of the drillholes had been arrange and positioned with a Garmin GPS mannequin “GPSmap 62s” (4m accuracy).
• Surveys are collected utilizing a Reflex EZ-Shot® single-shot digital instrument with readings collected at intervals of roughly each 30 m downhole plus a studying on the backside of the outlet.
• The situation of the drillholes and the aiming factors for the orientation of the drillholes are recorded on the historic drill logs and related maps.

• The grid system used is UTM NAD83 (Zone 18).
• Traditionally, the grid system used was the Copper Rand mine grid which has been transformed to UTM NAD83 (Zone 18).

• A Digital Terrane Mannequin (DTM) has been used to precisely plot the vertical place of the holes, which is taken into account to offer an ample stage of topographic management.

• The drill spacing for latest drilling is taken into account acceptable for the sort of exploration.
• As a result of historic nature and mixture of underground and floor drilling the drill gap spacing for historic drill outcomes is very variable.

• No useful resource estimation is made.

• No pattern compositing has been utilized.

• Latest drilling is oriented roughly at proper angles to the at the moment interpreted strike of the identified interpreted mineralisation.
• As a result of historic nature and mixture of underground and floor drilling the drill gap orientation for historic drill outcomes is very variable.

• No bias is taken into account to have been launched by the present sampling orientation.

• Core was positioned in wood core containers near the drill rig by the drilling contractor. The core was collected day by day by the drilling contractor and delivered to the safe core logging facility. Entry to the core logging facility is proscribed to Cygnus staff or designates.
• As a result of historic nature of the above reported historic outcomes detailed details about pattern safety isn’t accessible, subsequently the info might be unreliable.

• No audits or opinions of sampling strategies or knowledge have been undertaken, subsequently info on audits or opinions isn’t but accessible.

• The information reported inside this announcement is from the Chibougamau Mission. The Chibougamau challenge consists of three properties which embrace:
  • Copper Rand (1 mining license, 19 mining concession and 147 exploration claims)
  • Nook Bay – Devlin (1 mining license, 111 exploration claims)
  • Joe Mann (2 mining concessions, 74 exploration claims)
• Copper Rand and Nook Bay – Devlin are held 100% by CBAY Minerals Inc (“CBAY”), a completely owned subsidiary of Cygnus.
• 2732ha of the Joe Mann property is held by CBAY and three,029.6ha held underneath a 65%/35% JV settlement with SOQUEM (35%).
• The properties collectively making up the Mission are in good standing primarily based on the Ministry of Power and Pure Assets (Ministère de l’Énergie et des Ressources Naturelles) GESTIM declare administration system of the Authorities of Québec.

• All tenure is in good standing.

• The Chibougamau Copper and Gold challenge comprising Nook Bay, Devlin, Cedar Bay and Joe Mann has seen an intensive exploration historical past courting again to the early 1900s. The Preliminary Financial Evaluation (as referred to within the Firm’s announcement of 15 October 2024) offers an in depth historical past of the exploration actions undertaken by earlier explorers.
• Nook Bay was first recognized as a prospect in 1956
  • 1956 – 1972 eight drilling packages totalling 1,463 m and varied geophysical and electromagnetic (EM) surveys
  • 1973 – 1981 Riocanex and Flanagan McAdam: floor geophysical surveys and 43 diamond drill holes
  • 1982 – 1984 Riocanex and Nook Bay Exploration: 38 drill holes and metallurgical check work
  • 1988 – 1991 Nook Bay Exploration: diamond drilling, geophysical surveys and geological characterisation with preliminary MRE
  • 1992 – 1994 SOQUEM optioned and purchased a 30% curiosity, and accomplished diamond drilling
  • 1994 Explorations Cache Inc and Assets MSV Inc: diamond drilling
  • 2004 – 2006 GéoNova and MSV: 98 diamond drill holes and first Technical Report on the Nook Bay challenge reporting a MRE
  • 2007 – 2009 Campbell: diamond drilling and bulk pattern
  • 2012 – 2019 CBAY / AmAuCu: diamond drilling and MRE
• Devlin recognized in 1972 by airborne survey flown by the MERN
  • 1979 – 1981 diamond drilling, geophysical surveys
  • 1981 growth commenced
• Joe Mann recognized in 1950 with the graduation of mining actions occurring in 1956
  • The Joe Mann mine operated underground throughout three completely different durations from 1956 to 2007
  • In July 2012, Assets Jessie acquired the Joe Mann mine property, however carried out solely floor exploration work
• Cedar Bay was found previous to 1927 by Chibougamau McKenzie Mines Ltd
  • From preliminary discovery to 2013 varied floor and underground drilling campaigns and geophysical surveys undertaken by varied firms
• Colline was first found with mapping and sampling after which drilled within the Fifties with comply with up drilling in 1955.
  • In the1950s a shaft was sunk however the deposit was by no means mined.
  • The deposit was later examined with three drillholes and 6 regional drillholes all through two drilling campaigns in 1984 and 1986/87.
  • Exploration at Colline has been halted traditionally with the invention of and deal with different deposits within the area.

• Nook Bay and Devlin are positioned on the northeastern extremity of the Abitibi subprovince within the Superior province of the Canadian Defend and are examples of Chibougamau-type copper-gold deposits. The Abitibi subprovince is taken into account as one of many largest and best-preserved greenstone belts on the earth and hosts quite a few gold and base steel deposits.
• The Nook Bay deposit is positioned on the southern flank of the Doré Lake Complicated (DLC). It’s hosted by a N 15° trending shear zone roughly steady with a powerful 75° to 85° dip in direction of the west. The host anorthosite rock is sheared and sericitized over widths of two m to 25 m. The deposit is lower by a diabase dyke and is proscribed to the north by a fault construction and to the south by the LaChib deformation zone.
• The Nook Bay deposit consists of three important mineralized lodes (subparallel Important Lode 1 and Important Lode 2 above the dyke, and Important Lode beneath the dyke that make up the majority of the deposit. The Nook Bay deposit has been traced over a strike size to over 1,100 m to a depth of 1,350 m and stays open at depth.
• The mineralization is characterised by veins and/or lenses of large to semi-massive sulphides related to a brecciated to domestically large quartz-calcite materials. The sulphide assemblage consists of chalcopyrite, pyrite, and pyrrhotite with lesser quantities of molybdenite and sphalerite. Late remobilized quartz-chalcopyrite-pyrite veins happen in a large halo round the primary mineralization zones.
• Devlin is a flat-lying, copper-rich lodes-hosted deposit in a polygenic igneous breccia that’s lower than 100 m from the floor. The tabular our bodies have been modelled as 4 practically horizontal lodes: a extra steady decrease zone and three smaller lodes comprising the higher zone. Mineralization is mirrored as a fracture zone usually composed of two or extra sulphide-quartz lodes and stringers. Thickness of the mineralized zones vary from 0.5 m to 4.4 m. It has been diluted throughout modelling to mirror a minimal mining top of 1.8 m.
• The Joe Mann deposit is characterised by east-west placing shear hosted lodes that reach past 1,000 m vertically with mineralization recognized over a 3 km strike size. These shear zones type a part of the Opawica-Guercheville deformation zone, a significant deformation hall slicing the mafic volcanic rocks of the Obatogamau Formation within the north a part of the Caopatina Phase. The gabbro sill hosts the Important Zone and the West Zone on the mine, whereas the South Zone is discovered within the rhyolite. These three subvertical E-W (N275°/85°) ductile-brittle shear zones are sub-parallel to stratigraphy and to at least one one other, with as much as 140 m to 170 m of separation between them. These shear zones are hosted inside a stratigraphic bundle composed of iron-magnesium (Fe-Mg) carbonate and sericite altered gabbro sills, sheared basalts, and intermediate to felsic tuffs intruded by varied felsic intrusions. The Joe Mann gold mineralization is hosted by decimetre scale quartz-carbonate lodes (Dion and Guha 1988). The lodes are mineralized with pyrite, pyrrhotite, and chalcopyrite disposed in lens and lodelets parallel to schistosity, and infrequently seen gold. There are another minor, mineralized buildings, e.g., North and South-South Zones, with restricted vertical and horizontal extensions.

• easting and northing of the drill gap collar
• elevation or RL (Decreased Stage – elevation above sea stage in metres) of the drill gap collar
• dip and azimuth of the outlet
• down gap size and interception depth
• gap size.

If the exclusion of this info is justified on the idea that the knowledge isn’t Materials and this exclusion doesn’t detract from the understanding of the report, the Competent Individual ought to clearly clarify why that is the case.

• All requisite drillhole info is tabulated elsewhere on this launch. Refer Appendices A, B and C of the physique textual content.

• For latest outcomes and historic drilling at Nook Bay and Colline, drill gap intersections are reported above a decrease cut-off grade of 1% copper or 0.5g/t gold over widths of better than 1m.

• A most of 3m inside waste was allowed.

• Particular person grades for the metals included within the steel equivalents calculation for the exploration outcomes are in Appendices A, B and C of this launch. Metallic equivalents have been calculated at a copper worth of US$8,750/t, gold worth of US$2,350/ozand silver worth of US$25/oz. Copper equal was calculated primarily based on the system CuEq(%) = Cu(%) + (Au(g/t) x 0.77258)+(Ag(g/t) x 0.00822) . Metallurgical restoration elements have been utilized to the copper equivalents calculation, with copper metallurgical restoration assumed at 95% and treasured steel (gold and silver) metallurgical restoration assumed at 85% primarily based upon historic manufacturing on the Chibougamau Processing Facility and the metallurgical outcomes contained in Cygnus’ announcement dated 28 January 2025. It’s the Firm’s view that every one parts within the copper equal calculations have an affordable potential to be recovered and bought.

If the geometry of the mineralisation with respect to the drill gap angle is thought, its nature must be reported.

If it isn’t identified and solely the down gap lengths are reported, there must be a transparent assertion to this impact (eg ‘down gap size, true width not identified’).

• All intersections reported within the physique of this launch are down gap.
• For latest drill holes, holes are drilled as near orthogonal to the aircraft of the mineralized lodes as doable.
• For Nook Bay – true width is between 60-75% of the downhole intersection relying on the dip angle.
• For Colline – true width is estimated to be 80% of the downhole intersection.
• As a result of historic nature of drilling at Colline and variability of drilling orientation solely. downhole size is reported and true width isn’t identified.

• Refer Determine 1 and a pair of within the physique of the announcement.
• Extra lengthy part of Colline displaying location of latest outcomes and choose historic drilling in Determine 3 beneath.
• Plan map of infill drilling at Nook Bay in Determine 4 beneath.

• Latest infill drilling at Nook Bay totals 4 holes for two,232m. All outcomes better than 1% Cu or 0.5g/t Au have been reported at better than 1m width.
• Latest drilling at Colline totals 9 holes for two,896m. All outcomes better than 1% Cu or 0.5g/t Au have been reported at better than 1m width.
• Historic drilling at Colline totals 46 holes for 8,508m. All outcomes better than 1% Cu or 0.5g/t Au have been reported at better than 1m width.

• There is no such thing as a different substantive exploration knowledge.

Diagrams clearly highlighting the areas of doable extensions, together with the primary geological interpretations and future drilling areas, offered this info isn’t commercially delicate.

• The Firm plans to conduct drill testing of extra mineralisation in addition to step out drilling of current lodes to additional improve the sources quoted on this launch. Extra info is offered within the physique of this report.
• Diagrams in the primary physique of this launch present areas of doable useful resource extension on current lodes. The corporate continues to establish and assess a number of different goal areas inside the property boundary for added sources.
